Magnification
1-6x
Objective Lens Dia
24 mm
Focal Plane
Second Focal Plane
Eye Relief
100 mm / 4.0 in
Lens Coating
Fully Multi-coated
Linear Field of View @ 100 yd
125.15-20.84 ft @ 100 yards
Linear Field of View @ 100 m
41.71-6.95 m @ 100 meters
Angular Field of View °
23.9-3.98 °
Reticle
German #4
Tube Dia
30 mm
Parallax Setting
100 Yards
Click Value
1/2 MOA
Turret Function
N/A
Elevation Adjustment Range
140 MOA
Windage Adjustment Range
140 MOA
Diopter Compensation
-3 to +2
Illumination Setting
6 Gears
Battery Type
CR2032
Waterproof
IP67
Fogproof
Nitrogen Filled
Shockproof
750 G
Housing Material
6061-T6 Aluminum Alloy
Finish
FDE
Length
283 mm / 11.1 in
Weight
480 g / 16.9 oz
Items in the Package
Spare 1/2 MOA Turret, Lens Caps, Plastic Wrench, Cleaning Cloth etc.
