Magnification
1-6x
Objective Lens Dia
24 mm
Focal Plane
Second Focal Plane
Eye Relief
100 mm / 4.0 in
Lens Coating
Fully Multi-coated
Linear Field of View @ 100 yd
105.01 - 18 ft @ 100 yards
Linear Field of View @ 100 m
35 - 6 m @ 100 meters
Angular Field of View °
20.05 - 3.44 °
Reticle
VTC-SMIL
Tube Dia
30 mm
Parallax Setting
100 m
Click Value
1/10 MIL
Turret Function
Turret Lock
Elevation Adjustment Range
≥ 60 MIL
Windage Adjustment Range
≥ 60 MIL
Diopter Compensation
-2 to +2
Illumination Setting
6 Gears, Red, On/Off Switch
Battery Type
CR2032
Waterproof
IP67
Fogproof
Nitrogen Filled
Shockproof
1000 G
Housing Material
6061-T6 Aluminum Alloy
Finish
Matte Black
Length
264 mm / 10.4 in
Weight
537 g / 18.9 oz
Items in the Package
Lens Caps, User Manual, Plastic Wrench, Hex Key, Cleaning Cloth, 30mm Picatinny Rings, etc
