Magnification
1-6x
Objective Lens Dia
24 mm
Focal Plane
Second Focal Plane
Eye Relief
95 mm / 3.74 in
Exit Pupil
7.2-3.5 mm
Lens Coating
Fully Multi-coated
Linear Field of View @ 100 yd
117.6-20.4 ft @ 100 yards
Linear Field of View @ 100 m
39.2-6.8 m @ 100 meters
Angular Field of View °
22.6-3.9 °
Reticle
German #4, Fiber Center Dot
Tube Dia
30 mm
Side Focus
100 yards
Click Value
1/2 MOA
Turret Function
Zero Stop
Elevation Adjustment Range
120 MOA
Windage Adjustment Range
120 MOA
Diopter Compensation
-2 to +2
Illumination Setting
6 Gears, On/Off Switch
Battery Type
CR2032
Waterproof
IP67
Fogproof
Nitrogen Filled
Shockproof
1000 G
Housing Material
6061-T6 Aluminum Alloy
Finish
Matte Black
Length
283 mm / 11.1 in
Weight
478 g / 16.9 oz
Items in the Package
User Manual, Cleaning Cloth, Lens Caps, Spare Elevation Turret, etc.
