Magnification
10x
Objective Lens Dia
42 mm / 1.6 in
Exit Pupil
4.2 mm / 0.16 in
Eye Relief
19 mm
Lens Coating
Broadband Anti-Reflection Coating
Prism Glass
BK-7 Prism
Focusing System
Central
Linear Field of View
278 ft @ 1000 yds
Linear Field of View
93 m @ 1000 m
Angular Field of View
5.32 °
Diopter Compensation
-5 to +5
Min Focal Distance
6 yards
Range to Reflective Target(yards)
≥2500 yd
Range to the Building (Concrete)
≥1700 yd
Range to Big Trees
≥1500 yd
Range to Deer
≥800 yd
Scan Mode
Yes, <2s
Auto Shutoff
Yes, 30s
Range Acquisition Time
<0.5s (<100 yd), <1.5s (≥100 yd)
Measuring Accuracy
±1@<300yd, ±2@300-1500yd
Inclinomete
±60°
Inclinometer Accuracy
±1° @ >-30° or <30°,±2° @-30 to -60° or 30-60°
Laser Type
Laser Diodes 905nM
Yards/ Meters Mode
Yes
Battery Type
CR2
Working Temperature
-10° to 50°
Waterproof
IP67
Housing Material
PPS Plastic
Weight
862 g / 30.4 oz
Items in the Package
Pouch, Cleaning Cloth, Lens Caps, Strap, etc.
