VictOptics S4 4-16x44 First Focal Plane Riflescope

Item No :OPFF-01

Register / Sign In to See Prices
Find a Dealer

Feature Specification Reticle FAQ Relations Download

First Focal Plane, Edge-to-Edge Image, 96mm 3.8" Long Eye Relief, Crystal Clear

1/10MIL Adjustment with Turret Lock Feature, VIS-FMIL Etched Glass Reticle

30mm Monotube, Wide Field of View, Side Focus Min at 15 Yds, Power Ring Lever


OPFF-01 S4 4-16x44 FFP Diagram 1


OPFF-01 S4 4-16x44 FFP Diagram 2


OPFF-01 S4 4-16x44 FFP Diagram 3


OPFF-01 VI S4 Dimensions

  • Magnification: 4-16x
  • Objective Lens: 44mm
  • Ocular Lens Dia: 35mm / 1.4 inch
  • Ocular Length: 58mm / 2.3 inch
  • Exit Pupil: 11.0-2.75mm
  • Tube Diameter: 30mm
  • Length: 315mm / 12.4 inch
  • Weight (net): 518g / 18.3oz
  • Eye Relief: 96mm / 3.8 inch
  • Field of View (@100yds): 28.8-7.2 feet
  • Optics Coating: Fully-multi coated
  • Reticle: VIS-FMIL etched glass reticle
  • Click Value: 1/10MIL
  • Evaluation Range: 15MIL
  • Windage Range: 15MIL
  • Parallax Adjustment: 15 Yds to infinite
  • Finish: Black matte
  • Illumination: N/A
  • Exclusive for air gun and .22 LR rimfire etc benchrest shooting and hunting
  • Side focus knob marked 15, 20, 25, 30, 50, 75, 100, 200, 400, 600 yards to infinite
  • Distance between objective lens part and middle turret: 45mm (1.8 inch)
  • Length of middle turret part: 42mm (1.6 inch)
  • Distance between middle turret parts to power ring: 52mm (2.0 inch)
  • Shock tested to 750g, IPX4 water resistant and fully nitrogen purged
  • Turret lock system. Pull to adjust, Depress to lock.
  • High quality 6061 T6 aircraft grade aluminum
  • Diopter compensation from fast-focus eyepiece -2 to +2
  • Including items: one pair of 30mm weaver scope rings, power ring lever, 3 inch sunshade, big side wheel, cleaning cloth, instruction, lens flip-up caps
